Description
Cable protector refers to a broad category of products designed to organize, manage, and physically protect cables and wires, as well as the people around them. It is also called cable ramp, cable cover, cord protector and wire protector. The cable protector is composed of rubber base and PVC cover that shield cables from damage and prevent tripping hazards. The heavy duty rubber cable protector is durable, flexible, weather-resistant which are frequently used outdoors and in warehouses. The lightweight cable protector is usually used for indoor office use, often clear or low-profile.It is typically used in many cases like across walkways, driveways, event stages, offices, industrial floors.
Specification
Model | ES-CP3S | ES-CP3L |
Overall Size | 1000*300*50mm | 900*500*70mm |
Channel Size | 33*33mm | 55*65mm |
Weight | 5kgs | 14.5kgs |
Base Material | Rubber | |
Cover Material | PVC Cover | |
Color | Black | |
Applications | Events & | |
Performance
Loading Capacity: | 10-25 tons dynamic pressure resistance on the condition that filled with cables well. (The load capacity will vary due to environment, temperatures and surfaces.) |
Using Temperature: | -32℃ ~ +65℃. |
Tensile | 1.85MPa |
Elongation: | 24% |
Shore | 78° |
Advantages
1.Safe, non-conductive PVC top with recycled rubber base.
2.Protect pedestrians from dangerous trip & fall hazards.
3.Protect expensive cables, cords & hoses from vehicle damage.
4.Easy placement & removal of cables/hose lines with open-top style.
5.Interlocking two, three & five-slot systems, to build the length you need.
6.Cable Protectors can play a role in reducing the damage to the tire because of their soft slope.
7.Special process can ensure that colors of cable protectors are bright, not easy to fade.
8.Cable Protectors can be easily installed.
